19" Rack Cabinet, 28U x 450mm - 953.528UK
19" Rack Cabinet, 28U x 450mm - 953.528UK
Couldn't load pickup availability
Cabinet for 19" rack-mounted equipment with removable side panels and lockable front glass door. Constructed from cold rolled steel with folded edges for strength and stability. Front and rear rack strip is supplied and mounted to rails inside the cabinet, enabling the mounting depth to be adjusted to accommodate equipment with overhanging fittings or to support the rear of heavy units. The top panel is vented for cooling and has a cut-out for mounting a cooling fan if required. The front door is removable and has a pane of 5mm tempered glass flanked by folded steel edge panels which can be mounted to open to either the left or right. The rear panel has fixing apertures for wall mounting or alternatively, the cabinet can be free standing. Superbly designed, secure containment for professional rack installations.
Features
- Durable epoxy powder coated finish
- Clip-in side panels for easy access
- Wall mountable or free-standing
- Easy to assemble with adjustable front and rear rack strips
- Top and bottom knock-outs for cable feeds
- Supplied with glass door, lock, and two keys
- Material: 1.2mm cold rolled steel and 5mm tempered glass
- Maximum load: 100kg static
| Specifications | |
|---|---|
| Cabinet Type | 19 Inch Equipment |
| Product Range | ADASTRA Rack Enclosures |
| Rack U Height | 28U |
| External Height - Imperial | 53" |
| External Depth - Imperial | 17.7" |
| Enclosure Material | Steel |
| External Height - Metric | 1345mm |
| External Depth - Metric | 450mm |
| Country of Origin: | China |
