19370K 4A Littelfuse Wickmann Fuse, TR5 Quick Blow 4A
19370K 4A Littelfuse Wickmann Fuse, TR5 Quick Blow 4A
Regular price
£1.99 GBP
Regular price
Sale price
£1.99 GBP
Unit price
/
per
Tax included.
Shipping calculated at checkout.
Couldn't load pickup availability
Product Features
- FUSE, TR5 QUICK BLOW 4A
Product Details
| Blow Characteristic: | Quick Blow |
| Breaking Capacity: | 40A @ 250V AC |
| Fuse Case Style: | Radial Leaded |
| Fuse Current: | 4A |
| Fuse Size Imperial: | 0.33" x 0.3" |
| Fuse Size Metric: | 8.5mm x 8mm |
| Series: | TR5 |
| Voltage Rating V AC: | 250V |
| Approval Bodies: | IEC / SEMKO / UL / VDE |
| Body Diameter: | 8.5mm |
| Breaking Capacity Current AC: | 40A |
| External Depth: | 6.5mm |
| External Height: | 3.9mm |
| External Length / Height: | 8mm |
| External Width: | 3.7mm |
| Fuse Breaking Capacity Voltage AC: | 250V |
| Fuse Mounting: | Through Hole |
| Fuse Type Blowing Characteristic: | Quick Blow |
| Lead Diameter: | 0.6mm |
| Lead Length: | 4.3mm |
| Lead Spacing: | 5mm |
| Package / Case: | Radial |
Product Range information
The information below is for the range this product is part of and may not be information specific to the product, please contact us if you are unsure of any of the details.
Product Range Specifications
| Technical Data | |
| Rated Voltage | 250 |
| Breaking capacity | 35 |
| whichever is greater. |
