SF-1600F14HG(BK) SuperFlower Leadex Gold 1600W Fully Modular "80 Plus Gold" Power Supply

SuperFlower, one of the worlds leading power supply manufacturers have added the Leadex 1600W Gold to their range, offering up to 90% efficiency with class leading features, as well as offering a huge 1600W capacity, one of the highest wattage Gold rated PSU's on the market.

The SuperFlower Leadex Gold 1600W Power Supply features a fully modular design, 140mm silent DBB Fan, full Japanese 105°C capacitors, ECO Intelligent Thermal control system, a huge amount of connectors and single rail design.

100% Full Modular Cabling Design For Easy Cable Management

80 PLUS ® Gold Certified, 87% 90% 87% Efficiency At 20% 50% 100% Rated Load

Full Range Auto Voltage Detection Design 100V~240V (Active PFC)

Comply With ATX 12V. V2.2, EPS 12V. V2.91 & SSI EPS 12V. V2.92 Specification

Comply With Energy Star Standard & EuP (Energy Using Products) Regulation

Over Voltage Protection / Over Current Protection / Over Power Protection / Short Circuit Protection / Under Voltage Protection / Over Temperature Protection

Support All Intel/AMD Multi-Core CPU & ATX/BTX Compatible Motherboards

Support NVIDIA® SLI™ & ATI CrossFireX™ High Performance Graphic Card

Patented Easy To Use & Install Crystal Clear Cube Connectors with LED

Unleaded Green Materials with RoHS/WEEE Compliance

Perfect For Professional & High Performance Gaming System

Fan: 140 mm DBB(automatic control, semi-passive)

Efficiency: max. 90% (115V), 80 Plus Gold certificate

Safety: cTUVus/TUV/CB/CE/FCC/C-Tick/BSMI/RoHS/CCC

• The SuperFlower Leadex Gold 1600W Power Supply features a fully modular design, 140mm silent DBB Fan, full Japanese 105°C capacitors, ECO Intelligent Thermal control system, a huge amount of connectors and single rail design.
• 100% Full Modular Cabling Design For Easy Cable Management
• 80 PLUS ® Gold Certified, 87% 90% 87% Efficiency At 20% 50% 100% Rated Load
• Full Range Auto Voltage Detection Design 100V~240V (Active PFC)
• Comply With Energy Star Standard & EuP (Energy Using Products) Regulation
• Over Voltage Protection / Over Current Protection / Over Power Protection / Short Circuit Protection / Under Voltage Protection / Over Temperature Protection
• Support All Intel/AMD Multi-Core CPU & ATX/BTX Compatible Motherboards
• Support NVIDIA® SLI™ & ATI CrossFireX™ High Performance Graphic Card
• Patented Easy To Use & Install Crystal Clear Cube Connectors with LED
• More than 2,000 times On/Off test
• Unleaded Green Materials with RoHS/WEEE Compliance
• Perfect For Professional & High Performance Gaming System
• Dimensions: 150 x 86 x 220 mm (W x H x D)
• Fan: 140 mm DBB(automatic control, semi-passive)
• Colour: Black (power supply, fan)
• Fully Modular Design
• Efficiency: max. 90% (115V), 80 Plus Gold certificate
• Active PFC
• Form Factor: ATX12V 2.2 / EPS12V 2.92
• Power: 1600W
• 3.3V: 24 A
• 5V: 24 A
• 3.3V & + 5V combined: 120 W
• 12V: 1,599.6 W / 133.3 A
• 12V: 6 W / 0.5 A
• 5VSB: 15 W / 3.0 A
• Safety: cTUVus/TUV/CB/CE/FCC/C-Tick/BSMI/RoHS/CCC
• Partcode: SF-1600F14HG
• Connectors
• 1 x 20+4-Pin ATX12V/EPS12V
• 1 x 8-Pin EPS12V
• 1 x 4+4-Pin ATX12V/EPS12V
• 9 x 6+2-Pin-PCIe
• 5 x 6-pin PCIe
• 18 x SATA
• 5 x 4-Pin-Molex
• 2 x Floppy
• Warranty: 5yr
