1-Channel Arbitrary Waveform Generator, 20MHz - 33511B
1-Channel Arbitrary Waveform Generator, 20MHz - 33511B
Regular price
£2,627.09 GBP
Regular price
Sale price
£2,627.09 GBP
Unit price
/
per
Tax included.
Shipping calculated at checkout.
Couldn't load pickup availability
The 33500B Series waveform generators offer the common signals and features you expect, such as modulation, sweep, and burst. But the 33500B Series offers many more features that give you the capabilities and fl exibility you need to get your job done. Like an intuitive front-panel user interface that makes it easy to quickly relearn it when you've been focused elsewhere. Like built-in LAN, USB and GPIB interfaces that make it easy to control your instruments or transfer your waveforms to your instrument.
Features
- So you can perform deeper testing - see One Page Summary for further information
- 20 MHz, 1-channel
- Jitter: < 40 ps
- THD: < 0.04%
- Amplitude ranges: 1 mVpp up to 10 Vpp
- 250 MSa/s sampling rate
- 16-bit amplitude resolution
- 1 MSa/channel memory, 16 MSa optional
- Waveform generator with arb capability
| Specifications | |
|---|---|
| Signal Generator Type | Arbitrary |
| No. of Channels | 1 Channel |
| Product Range | 33500B Series |
| Bandwidth | 20MHz |
| Signal Generator Modulation | AM, BPSK, FM, FSK, PM, PWM, Sum |
| Manufacturer Warranty | 3 Years |
| Plug Type | EU, UK |
| Product Contents: | BenchVue software license (BV0002B) is now included with your instrument. BenchVue makes it simple to connect, control instruments, and automate test sequences. |
| Important Product Info: | In addition, we offer calibration services for this product. Choose from a Standard Certificated Service or an internationally recognised UKAS accredited calibration. Visit our calibration service page for more details. |
| Country of Origin: | Malaysia |
