10 Position SMD Rotary Coded Switch, 24V DC, Decimal, 25mA, 7x7mm - MCR7M4-10RA-V-B
10 Position SMD Rotary Coded Switch, 24V DC, Decimal, 25mA, 7x7mm - MCR7M4-10RA-V-B
Regular price
£2.49 GBP
Regular price
Sale price
£2.49 GBP
Unit price
/
per
Tax included.
Shipping calculated at checkout.
Couldn't load pickup availability
The MCR7M4-10RA-V-B is a 10-position through-hole Rotary Coded Switch with flushed high-temperature thermoplastic actuator. It has stainless steel block, piano wire spring plate, black high-temperature thermoplastic base and nickel silver cover.
Features
- UL94V-0 Flammability rating
- 20000-step Electrical life
- 25mA at 24VDC Switching rating
- 20000-step Mechanical life
- -30 to 80°C Operation temperature range
- Multicomp Pro products are rated 4.6 out of 5 stars
- 12 month limited warranty *view Terms & Conditions for details
- 96% of customers would recommend to a friend
| Specifications | |
|---|---|
| Switch Mounting | Surface Mount |
| No. of Switch Positions | 10 Position |
| Switching Voltage | 24VDC |
| Output Code | Decimal |
| Switching Current | 25mA |
| Actuator Level | Flushed |
| Country of Origin: | China |
