10 Way Vertical Pluggable Terminal Block Header, 16A, 5mm Pitch - MC000166
10 Way Vertical Pluggable Terminal Block Header, 16A, 5mm Pitch - MC000166
Regular price
£4.19 GBP
Regular price
Sale price
£4.19 GBP
Unit price
/
per
Tax included.
Shipping calculated at checkout.
Couldn't load pickup availability
The MC000166 is a 10-way 16A pluggable Terminal Block Header with tin-plated brass solder pin and green polyamide 66 insulating body. It has through-hole vertical block orientation and 2000VAC minimum insulation withstand voltage.
Features
- >2000MR at 500VDC Insulation resistance (Maximum)
- -40 to 105°C Operating temperature range
- Multicomp Pro products are rated 4.6 out of 5 stars
- 12 month limited warranty *view Terms & Conditions for details
- 96% of customers would recommend to a friend
| Specifications | |
|---|---|
| Gender | Header |
| Pitch Spacing | 5mm |
| No. of Positions | 10Ways |
| Rated Current | 16A |
| Rated Voltage | 300V |
| Block Orientation | Through Hole Vertical |
| Important Product Warning: | Market demand for this product has caused an extension in leadtimes. Delivery dates may fluctuate. Product exempt from discounts. |
| Country of Origin: | Taiwan |
