100MHz Oscillator, 50ppm, SMD, 7mm x 5mm, 3.3V - 7W-100.000MBB-T
100MHz Oscillator, 50ppm, SMD, 7mm x 5mm, 3.3V - 7W-100.000MBB-T
Regular price
£4.89 GBP
Regular price
Sale price
£4.89 GBP
Unit price
/
per
Tax included.
Shipping calculated at checkout.
Couldn't load pickup availability
The 7W series SMD CMOS Crystal Oscillator (CXO) operating at a frequency range of 1 to 170MHz with ±50PPM frequency stability. It is suitable for use in wireless communication, PC and LCDM applications.
Features
- Small SMD seam sealed clock crystal oscillator unit
- High precision characteristic covering up to wide frequency range
- Optional stand-by function for tri-state output
- 1.8 to 5V Supply voltage range
- High stability, low jitter, low power consumption
| Specifications | |
|---|---|
| Frequency Nom | 100MHz |
| Frequency Stability + / - | 50ppm |
| Oscillator Case | SMD, 7mm x 5mm |
| Supply Voltage Nom | 3.3V |
| Product Range | 7W Series |
| Operating Temperature Min | -40°C |
| Operating Temperature Max | 85°C |
| Oscillator Output Compatibility | CMOS |
| Country of Origin: | Taiwan |
