10PWRA2405D Powerpax 10W Regulated DC-DC Converter DIP 24V In / + - 5V Out
10PWRA2405D Powerpax 10W Regulated DC-DC Converter DIP 24V In / + - 5V Out
Regular price
£15.59 GBP
Regular price
Sale price
£15.59 GBP
Unit price
/
per
Tax included.
Shipping calculated at checkout.
Couldn't load pickup availability
Product Description
This 10W regulated DC/DC converter is specifically designed for applications where a wide range input coupled with a regulated output that is isolated from the input is required.
Product Features
- Wide (2:1) Input Range
- DIP package
- Efficiency up to 86%
- 1.5kVDC Input/Output Isolation
- Short Circuit Protection(automatic recovery)
- Metal Shielding Package
- No Heat Sink Required
- Industry Standard Pinout
- MTBF 1000,000 hours
- RoHS Compliance
Product Details
| DC / DC Converter Mounting: | DIP |
| DC / DC Converter Output Type: | Fixed |
| DC / DC Converter Type: | Isolated POL |
| Depth: | 25.4mm |
| Height: | 11.2mm |
| Output Power Max: | 10W |
| Width: | 50.8mm |
