10W ABS Horn Speaker 70/100V/8R, IP66, EN54-24 - APH10T/ENC
10W ABS Horn Speaker 70/100V/8R, IP66, EN54-24 - APH10T/ENC
Couldn't load pickup availability
This weatherproof plastic music horn speaker is manufactured from ABS moulded, low smoke zero Halogen UL-94V0 plastic with UV inhibitors. Being non-corrosive and resistant to salty air makes it is suitable for both indoor and outdoor use. The horn is supplied with a high grade epoxy coated U-bracket. This range of plastic horns is fitted, as standard, with 1x PG9 gland and will open to 20mm plus 1x 20mm knockout allowing the installer to loop in/out the cabling thus avoiding the need for an additional junction box. The standard finish is grey RAL7035. Offering high efficiency and clarity of speech, these horns are suitable for speech or signal warnings in hostile environments. It is also ideal for marine and industrial applications as they stay unaffected by most chemicals. Its rugged construction and quick and easy installation make it ideally suited for such places as outdoor swimming pools, sports stadiums, leisure centres, shopping centres, military settings and railway stations.
Features
- Material: Low smoke zero Halogen plastic with UV inhibitors
- Mounting: Stainless steel U-bracket
- 70/100V tappings: 0.625/1.25/2.5/5/10W
- Output power: 10W at 8R
- Frequency response: 340Hz to 16kHz
- Max. SPL ( at 1m): 115dB
- Dispersion (HxV): 139°/173°
- IP rating: IP66
- Connection: Terminal block
- Dimensions (HxWxD): 131x172x227mm
- EN54-24 compliant
- Weight: 1.6kg
| Specifications | |
|---|---|
| Transformer Power Tappings | 0.625/1.25/2.5/5/10W |
| Frequency Response Min | 340Hz |
| Frequency Response Max | 16kHz |
| External Height | 131mm |
| External Width | 172mm |
| External Depth | 227mm |
| Product Range | PENTON ABS Horn Speakers |
| Important Product Info: | EN54-24 2008, cert. No: 0359-CPD-0166 Type B |
| Country of Origin: | Taiwan |
