12 Bit Dual Voltage Output Digital to Analogue Converter with SPI Interface, 2.7V to 5.5V, SOIC, 14 Pins - MCP4922-E/SL
12 Bit Dual Voltage Output Digital to Analogue Converter with SPI Interface, 2.7V to 5.5V, SOIC, 14 Pins - MCP4922-E/SL
Regular price
£5.19 GBP
Regular price
Sale price
£5.19 GBP
Unit price
/
per
Tax included.
Shipping calculated at checkout.
Couldn't load pickup availability
The MCP4922-E/SL is a 12-bit dual-channel voltage output Digital-to-Analogue (DAC) Converter with SPI interface. This device offers high accuracy and low power consumption. Communication with the device is accomplished via a simple serial interface using SPI protocols. This device provide very high accuracy and low noise performance. The user can shut down both DAC channels by using SHDN pin or shut down the DAC channel individually by setting the configuration register bits. In shutdown mode, most of the internal circuits in the shutdown channel are turned off for power savings and the output amplifier is configured to present a known high resistance output load (500kR typical).
Features
- 12-bit Resolution
- 350μA (typical) Operating current
- External voltage reference pin
- 4.5μs Output settling time
- Rail-to-rail output
- Simultaneous latching of dual DACs with LDAC pin
- External voltage reference inputs
- External multiplier mode
| Specifications | |
|---|---|
| Resolution (Bits) | 12bit |
| Data Interface | Serial |
| Supply Voltage Range | 2.7V to 5.5V |
| ADC / DAC Case Style | SOIC |
| No. of Pins | 14Pins |
| Input Channel Type | Serial |
| Operating Temperature Min | -40°C |
| Operating Temperature Max | 125°C |
| Automotive Qualification Standard | AEC-Q100 |
| Important Product Warning: | Market demand for this product has caused an extension in leadtimes. Delivery dates may fluctuate. Product exempt from discounts. |
| Country of Origin: | United States |
