12-Pole Plug & Socket Terminal Block, 450VAC, 45A, 12mm Pitch, Polyamide PA6.6 - HY434/12 NYSP
12-Pole Plug & Socket Terminal Block, 450VAC, 45A, 12mm Pitch, Polyamide PA6.6 - HY434/12 NYSP
Regular price
£9.09 GBP
Regular price
Sale price
£9.09 GBP
Unit price
/
per
Tax included.
Shipping calculated at checkout.
Couldn't load pickup availability
The HY434/12 NYSP from Hylec is a 12-Pole plug and socket terminal block constructed from natural Polyamide PA6.6. The HY434/12 NYSP has a 12mm pitch and a rating of 28A at 450VAC.
Product Info
- UL94 rating: UL94V2
- Minimum conductor size: 10mm2
- Maximum voltage: 450VAC
- Maximum current: 45A
- Pitch: 12mm
- Dimensions (LxWxH): 140.4x23.2x20.3mm
- Diameter: 4.1mm
| Details | |
|---|---|
| Pitch Spacing | 12mm |
| No. of Positions | 12Ways |
| Conductor Area CSA | 10mm2 |
| Wire Connection Method | Screw |
| Rated Current | 45A |
| Rated Voltage | 450V |
| Product Range | HY434 Series |
| Country of Origin: | Italy |
