12MHz Crystal, SMD, 3.4mm x 2.7mm, 30ppm, 12pF - C3E-12.000-12-3030-X
12MHz Crystal, SMD, 3.4mm x 2.7mm, 30ppm, 12pF - C3E-12.000-12-3030-X
Regular price
£2.69 GBP
Regular price
Sale price
£2.69 GBP
Unit price
/
per
Tax included.
Shipping calculated at checkout.
Couldn't load pickup availability
The C3E-12.000-12-3030-X is a 3.2 x 2.5mm Low Profile Microprocessor Crystal with frequency range of 12 to 52MHz, seam sealed ceramic metal package. Load capacitance of 12pF and frequency stability ±30ppm and extended industrial temperature range.
Features
- Ageing ±3ppm per year (maximum)
- Fundamental mode
| Specifications | |
|---|---|
| Frequency Nom | 12MHz |
| Crystal Case | SMD, 3.4mm x 2.7mm |
| Frequency Stability + / - | 30ppm |
| Load Capacitance | 12pF |
| Frequency Tolerance + / - | 30ppm |
| Product Range | C3E |
| Operating Temperature Min | -40°C |
| Operating Temperature Max | 85°C |
| Important Product Warning: | Market demand for this product has caused an extension in leadtimes. Delivery dates may fluctuate. Product exempt from discounts. |
| Country of Origin: | Taiwan |
