12V, 12.5A, 150W, Enclosed Power Supply - LRS-150-12
12V, 12.5A, 150W, Enclosed Power Supply - LRS-150-12
Regular price
£46.29 GBP
Regular price
Sale price
£46.29 GBP
Unit price
/
per
Tax included.
Shipping calculated at checkout.
Couldn't load pickup availability
LRS-150 series 150W single output enclosed type power supply with 30mm of low profile design. Adopting the input of 115VAC or 230VAC (selectable by switch). It features high efficiency up to 90%, long life and high reliability.
Features
- Withstand 300VAC surge input for 3sec
- No load power consumption<0.5W
- Miniature size and 1U low profile
- High operating temperature up to 700C
- Short-circuit/overload/overvoltage/over temperature protection
- Cool by free air convection
- Compliance to IEC/EN 60335-1 and IEC/EN61558-1,2-16 for household appliances
- LED indicator for power on
- Dimension is 156mm x 97mm x 30mm
- Voltage Protection III
| Specifications | |
|---|---|
| Power Supply Approvals | ITE & Household |
| No. of Outputs | 1Outputs |
| Output Power Max | 150W |
| Output Voltage - Output 1 | 12V |
| Output Current - Output 1 | 12.5A |
| Input Voltage VAC | 85V AC to 264V AC |
| Power Supply Output Type | Adjustable, Fixed |
| Product Range | LRS-150 Series |
| Country of Origin: | China |
