12V, 16A, 192W, ITE, Enclosed Power Supply - HEP-240-12A
12V, 16A, 192W, ITE, Enclosed Power Supply - HEP-240-12A
Regular price
£172.59 GBP
Regular price
Sale price
£172.59 GBP
Unit price
/
per
Tax included.
Shipping calculated at checkout.
Couldn't load pickup availability
The HEP-240 series is a highly efficient 182-241.3W AC/DC enclosed power supply with the capabilty to operate under harsh humid and dusty environments house in a aluminium case potted with heat-conducted sillicone.
Features
- Built in power factor correction (0.92)
- 91.5% efficiency
- Cooling fan auto controlled
- Universal AC input
- IP65 Rated - IP68 optional
- Short circuit, overload, over voltage and over temperature protected
- 6-year warranty
- CE and CB approved
- Dimensions (HxWxD): 39x68x228mm
| Specifications | |
|---|---|
| Power Supply Approvals | ITE |
| No. of Outputs | 1Outputs |
| Output Power Max | 192W |
| Output Voltage - Output 1 | 12V |
| Output Current - Output 1 | 16A |
| Input Voltage VAC | 90V AC to 305V AC |
| Power Supply Output Type | Adjustable, Fixed |
| Product Range | HEP-240 Series |
| Important Product Warning: | Market demand for this product has caused an extension in leadtimes. Delivery dates may fluctuate. Product exempt from discounts. |
| Country of Origin: | Taiwan |
