12V, 850mA, 10.2W, PCB Mount AC to DC Power Supply - IRM-10-12

12V, 850mA, 10.2W, PCB Mount AC to DC Power Supply - IRM-10-12

£16.49 GBP
£16.49 GBP
Sale Sold out
Tax included. Shipping calculated at checkout.

IRM-10 series is a 10W miniature AC to DC module type power supply allows a universal input voltage range from 85VAC to 264VAC.

Features

  • EMI class B without additional components
  • Cooling by free air convection
  • Isolation ClassII incorporating the built-in EMI filtering components
  • Pass LPS
  • With high efficiency up to 82%

Specifications
Power Supply Approvals ITE
No. of Outputs 1 Output
Output Power Max 10.2W
Output Voltage - Output 1 12V
Output Current - Output 1 850mA
Power Supply Output Type Fixed
Input Voltage VAC 85V AC to 264V AC
Width 21.5mm
Height 25.4mm
Depth 45.7mm
Product Range IRM-10 Series
Country of Origin: China

EAN:
Manufacturer Part Number:
