15" 600W Bass Driver 8R - 15-600LF
15" 600W Bass Driver 8R - 15-600LF
Regular price
£152.79 GBP
Regular price
Sale price
£152.79 GBP
Unit price
/
per
Tax included.
Shipping calculated at checkout.
Couldn't load pickup availability
The Sovereign 15-600LF is a very high output bass driver in 2 way ported enclosures. The cone membrane, manufactured from curvilinear paper, is much stronger and more durable than conventional paper alternatives. This allows the driver to combine high sensitivity with the structural integrity required to produce undistorted low frequencies at high output levels. The mechanical and electrical properties of the unit have been carefully optimised to allow extended low frequency output up to its rated power handling of 600W (AES). The driver is ideally suited for medium to large vented enclosures.
Features
- For use in pro-sound applications
- Great for ported bass enclosure designs
- Optimised cone pulp offering increased strength, durability and performance
- 3" Copper voice coil
- Ideally suited for medium to large vented enclosures
- Magnet material: Ferrite
- Frequency response: 38Hz to 3.5kHz
- Baffle hole diameter:13.85"
- Chassis: Pressed Steel
- Connectors : Solder tag
- Output power: 2400W peak
- EBP: 89.37Hz (suitable for closed speakers)
- Dimensions (DxDia): 169x381mmØ
- Weight: 9.4kg
| Specifications | |
|---|---|
| Driver Type | Subwoofer |
| External Diameter - Metric | 381mm |
| Impedance | 8ohm |
| Power Rating Nom | 1.2kW |
| Sound Level SPL | 98.5dBA |
| Frequency Response Min | 38Hz |
| Frequency Response Max | 3.5kHz |
| Speaker Shape | Round |
| Resonant Frequency | 37Hz |
| Speaker Mounting | Through Hole |
| Power Rating Max | 2.4kW |
| External Depth - Metric | 169mm |
| Product Range | Fane Bass Drivers 8R |
| Country of Origin: | China |
