15A Single DC Motor Driver - DRI0042
15A Single DC Motor Driver - DRI0042
Regular price
£25.49 GBP
Regular price
Sale price
£25.49 GBP
Unit price
/
per
Tax included.
Shipping calculated at checkout.
Couldn't load pickup availability
DRI0042 is a 15A single DC motor driver. This is an ultra small size DC motor driver for room limited projects, while the impressive IC - LM2575 could provide a powerful way to drive 36V at 15A motors. Also its UVLO (Under Voltage Latch-Out) feature provides a safe guard for your system. Besides all, it is very considerate to own an 5V output for Arduino or any other devices, and its interface is ESD (electro-static discharge) protection.
Features
- Voltage supply range from 12VDC to 36VDC
- Voltage supply limit range from 6.5V to 40V
- Maximum continuous operating current is 12A (no heat sink)
- PWM speed
- Working temperature range from -25°C to 85°C
- M3 mounting hole
| Specifications | |
|---|---|
| Silicon Manufacturer | Analog Devices |
| Silicon Core Number | LM2575 |
| For Use With | Arduino UNO v3.0 [R3] Board |
| Kit Contents | DC Motor Driver LM2575 |
| Product Contents: | 15A Single DC motor driver x1. |
| Country of Origin: | China |
