16MHz Crystal, SMD, 11.4mm x 4.35mm, 10ppm, 18pF, 10ppm - 9C-16.000MEEJ-T
16MHz Crystal, SMD, 11.4mm x 4.35mm, 10ppm, 18pF, 10ppm - 9C-16.000MEEJ-T
Regular price
£1.79 GBP
Regular price
Sale price
£1.79 GBP
Unit price
/
per
Tax included.
Shipping calculated at checkout.
Couldn't load pickup availability
The 9C-16.000MEEJ-T is a 10ppm surface-mount Quartz Crystal with highly mass production capability. The 9C series crystal with higher frequency pull ability, lower equivalent series resistance and PC, STB, LCDM and cable modem applications.
Features
- Fundamental operation mode
- 30R Maximum equivalent series resistance
- 7pF Maximum shunt capacitance
- 500μW Maximum drive level
| Specifications | |
|---|---|
| Frequency Nom | 16MHz |
| Crystal Case | SMD, 11.4mm x 4.35mm |
| Frequency Stability + / - | 10ppm |
| Load Capacitance | 18pF |
| Frequency Tolerance + / - | 10ppm |
| Product Range | 9C Series |
| Operating Temperature Min | -40°C |
| Operating Temperature Max | 85°C |
| Country of Origin: | China |
