24MHz Crystal, SMD, 3.2mm x 2.5mm, 30ppm, 18pF - 7M-24.000MAAJ-T
24MHz Crystal, SMD, 3.2mm x 2.5mm, 30ppm, 18pF - 7M-24.000MAAJ-T
Regular price
£2.19 GBP
Regular price
Sale price
£2.19 GBP
Unit price
/
per
Tax included.
Shipping calculated at checkout.
Couldn't load pickup availability
The 7M-24.000MAAJ-T is a 3.2 x 2.5 x 0.7mm 30ppm surface-mount Quartz Crystal with seam sealing. The 7M series crystal with high precision and high frequency stability, extremely good for reducing EMI effect and for Bluetooth, wireless communication set, DSC, PDA and mobile phone applications.
Features
- Fundamental operation mode
- 60R Maximum equivalent series resistance
- 3pF Maximum shunt capacitance
- 100μW Maximum drive level
| Specifications | |
|---|---|
| Frequency Nom | 24MHz |
| Crystal Case | SMD, 3.2mm x 2.5mm |
| Frequency Stability + / - | 30ppm |
| Load Capacitance | 18pF |
| Frequency Tolerance + / - | 30ppm |
| Product Range | 7M Series |
| Operating Temperature Min | -40°C |
| Operating Temperature Max | 85°C |
| Country of Origin: | China |
