24MHz Crystal, SMD, 3.2mm x 2.5mm, 30ppm, 18pF - ABM8G-12.000MHZ-18-D2Y-T
24MHz Crystal, SMD, 3.2mm x 2.5mm, 30ppm, 18pF - ABM8G-12.000MHZ-18-D2Y-T
Regular price
£1.89 GBP
Regular price
Sale price
£1.89 GBP
Unit price
/
per
Tax included.
Shipping calculated at checkout.
Couldn't load pickup availability
The ABM8G-12.000MHZ-18-D2Y-T is a 3.2 x 2.5 x 1.0mm Ultra Miniature Ceramic Glass Sealed SMD Crystal. Low in height, suitable for thin equipment.
Features
- Glass Sealed Package Assures High Reliability and High Temperature Operation
- Tight Tolerance and Stability
- IR Reflow Capable
- Ageing ±3ppm Per Year Max
- 500MR Insulation Resistance
| Specifications | |
|---|---|
| Frequency Nom | 12MHz |
| Crystal Case | SMD, 3.2mm x 2.5mm |
| Frequency Stability + / - | 30ppm |
| Load Capacitance | 18pF |
| Frequency Tolerance + / - | 20ppm |
| Product Range | ABM8G Series |
| Operating Temperature Min | -40°C |
| Operating Temperature Max | 85°C |
| Country of Origin: | Taiwan |
