4 Channel Digital Storage Oscilloscope, 100MHz - TBS2104B
4 Channel Digital Storage Oscilloscope, 100MHz - TBS2104B
Regular price
£3,467.99 GBP
Regular price
Sale price
£3,467.99 GBP
Unit price
/
per
Tax included.
Shipping calculated at checkout.
Couldn't load pickup availability
The TBS2000B Series of Oscilloscopes with a 9" WVGA display, 5 million point record length and 2GS/s sample rate, capture and display significantly more signal to help you debug and validate the designs faster. Easily and confidently analyze your signals with new on-waveform cursor readouts and 32 automated measurements, each with informative tips. The TekVPI probe interface supports traditional passive BNC probes, but also enables wide application coverage with the latest active voltage probes and current probes.
Features
- TBS2000B series digital storage oscilloscope with 4 analogue channels and 100MHz bandwidth
- TekVPI probe interface supports active, differential and current probes with automatic scaling
- New front-end design enables more accurate measurements
- Search and mark features for easy identification of events that occur in the acquired waveform
- HelpEverywhere provides helpful on-screen tips for new users
- Built-in scope Intro handbook provides operating instructions and oscilloscope fundamentals
- Instrument user interface and the front panel overlay is translated into 10 languages
- USB 2.0 host, USB 2.0 device, 10/100BASE-T Ethernet ports and Wi-Fi interface
- 9inch WVGA colour display with 15 horizontal grids shows 50% more signal
- 32 automated measurements and FFT function for quick waveform analysis
- Introductory Offer: Up to 10% off, Get this next generation of TBS2000 at the same price as the old generation. Price already discounted. While stock lasts
| Specifications | |
|---|---|
| Product Range | TBS2000B Series |
| Scope Channels | 4 Channel |
| Bandwidth | 100MHz |
| Sampling Rate | 2GSPS |
| Display Memory Depth | 5 Mpts |
| Scope Display Type | WVGA TFT Colour |
| Kit Contents | OSC, TPP0100 Passive Probe, Cal Certificate, Power Cord, Compliance/Safety Instructions, Prog Manual |
| Manufacturer Warranty | 5 Years |
| Product Contents: | Oscilloscope, TPP0100 passive probe, Calibration certificate, Power cord, Compliance/safety instructions, Programing manual. |
| Country of Origin: | China |
