4 Pole speakON Socket Cable Connector, 30A, 250V AC - NLT4FXX
4 Pole speakON Socket Cable Connector, 30A, 250V AC - NLT4FXX
Regular price
£15.49 GBP
Regular price
Sale price
£15.49 GBP
Unit price
/
per
Tax included.
Shipping calculated at checkout.
Couldn't load pickup availability
The NLT4FXX from Neutrik is a 4 Pole speakON socket cable connector that is especially designed for heavy duty amplifier loudspeaker applications like professional touring.
Features
- IEC 61984 certifiedIEC 6236/-1 compliant
- Uses precise Quick Lock system
- Weatherproof built-in gasket meets IP54 protection class in mated condition
- Extremely robust metal housing and glass reinforced V-0 material insert designed for harsh and demanding environment
- Contact resistance: < 2mR
- Dielectric strength: 2.8kV AC
- Insulation resistance: >0.1 GR (afterpheat)
- Rated current per contact: 30A RMS continuous
- Rated voltage: 250V AC
- Outside cable diameter: 9 - 16mm
- Wiresize: 6mm2 / 10 AWG
| Specifications | |
|---|---|
| No. of Contacts | 4 Contact |
| Gender | Socket |
| Connector Mounting | Cable Mount |
| Contact Plating | Copper Alloy Plated Contacts |
| Connector Body Material | Nylon 6.6 (Polyamide 6.6) Body |
| Important Product Warning: | speakON is NOT to be used as an AC mains or power supply connector |
| Country of Origin: | Liechtenstein |
