4 Port RS232 Serial PCI-Ex Adaptor Card with 16950 UART, Full Size Bracket - PEX4S953
4 Port RS232 Serial PCI-Ex Adaptor Card with 16950 UART, Full Size Bracket - PEX4S953
Regular price
£134.49 GBP
Regular price
Sale price
£134.49 GBP
Unit price
/
per
Tax included.
Shipping calculated at checkout.
Couldn't load pickup availability
Provides four additional RS232 serial ports for your PC, ideal for connecting multiple legacy devices such as card readers, printers, PIN pads and modems. Serial connections are 9-pin D-Sub male via the included 4-way breakout cable and the board is fitted with a full size bracket.
Features
- Compatible with industry standard 16950 UART
- Maximum data transfer rate of 921.6kb/s thanks to the ASIX AX99100 chipset
- Provides 5/12V power output on pin 9 (when external power is connected)
- 256-byte depth FIFO cache per transmitter and receiver
- Supports 9, 8, 7, 6, 5 data bits (one per port)
- PCI-Express x1 interface
- Pre-fitted with full size bracket and supplied with Low Profile bracket
- Supports Win 7/8/10, Linux 2.4-2.6.x (LTS only)
- 2 Year manufacturer warranty
| Specifications | |
|---|---|
| Computer Interface | PCI Express |
| Product Contents: | Serial card, LP bracket, breakout cable and user guide |
| Country of Origin: | China |
