4G LTE Yagi Gain Antenna - ANT-4GYAG11
4G LTE Yagi Gain Antenna - ANT-4GYAG11
Regular price
£76.69 GBP
Regular price
Sale price
£76.69 GBP
Unit price
/
per
Tax included.
Shipping calculated at checkout.
Couldn't load pickup availability
A Miniature YAGI antenna with high performance gain. Suitable for GSM, 4G and LTE applications, this antenna will give optimum range and reliability to your application.
Features
- Suitable range improvement and space saving applications
- Log Period Yagi Directional
- Frequency range: 800MHz to 2500MHz
- Polarisation: Linear
- Active gain: +11dBi
- Dimensions: 442x200x60mm
- H: 45deg, V: 45deg
- ABS Case
- RG58 Lead to SMA (male)
- Ground plane Independent
- Mounting Bracket Supplied
- Weight: 490g
| Specifications | |
|---|---|
| Antenna Type | 4G / GSM / LTE / Yagi |
| Frequency Min | 800MHz |
| Frequency Max | 2.5GHz |
| Antenna Mounting | SMA Connector |
| Gain | 11dBi |
| VSWR | 2 |
| Input Impedance | 50ohm |
| Antenna Polarisation | Linear |
| Country of Origin: | China |
