5.08mm Modular PCB Terminal Block, 2 Way, 26AWG to 12AWG, Screw - MC000048
5.08mm Modular PCB Terminal Block, 2 Way, 26AWG to 12AWG, Screw - MC000048
Regular price
£1.49 GBP
Regular price
Sale price
£1.49 GBP
Unit price
/
per
Tax included.
Shipping calculated at checkout.
Couldn't load pickup availability
The MC000048 from Multicomp is a through hole, 2 position vertical terminal block with screw connection. This terminal block comes with 5.08mm pitch spacing and is suitable for wire size ranging from 26AWG to 12AWG. Modular terminal block, allowing combination with other modular or single type Multicomp terminal blocks.
Product Info
- Green colour insulation
- Polyamide66 housing material
- Brass terminal
- Tin plating
- Operating temperature range from -40°C to 105°C
- UL recognised
- Right angle wire orientation
- Multicomp products are rated 4.6 out of 5 stars
- 12 month limited warranty *view Terms & Conditions for details
- 96% of customers would recommend to a friend
| Details | |
|---|---|
| Pitch Spacing | 5.08mm |
| No. of Positions | 2Ways |
| Wire Size AWG Min | 26AWG |
| Wire Size AWG Max | 12AWG |
| Wire Connection Method | Screw |
| Rated Current | 16A |
| Rated Voltage | 300V |
| Block Orientation | Through Hole Right Angle |
| Product Range | MC00004 Series |
| Country of Origin: | Taiwan |
