5.08mm Modular PCB Terminal Block, 3 Way, 26AWG to 12AWG, Screw - MC000049
5.08mm Modular PCB Terminal Block, 3 Way, 26AWG to 12AWG, Screw - MC000049
Regular price
£1.69 GBP
Regular price
Sale price
£1.69 GBP
Unit price
/
per
Tax included.
Shipping calculated at checkout.
Couldn't load pickup availability
The MC000049 is a 3-position 5.08mm Terminal Block with polyamide 66 insulating body, nickel-plated steel cage clamp and screw, tin-plated brass terminal. Through hole right angle block orientation, 12 to 26AWG wire size and screw wire connection method. Modular terminal block, allowing combination with other modular or single type Multicomp terminal blocks.
Features
- 2000VAC Maximum insulating withstand voltage
- >2000MR at 500VDC Insulation resistance
- 4 to 5mm Wire strip length
- 7-inch.lbs Torque rating
- Multicomp products are rated 4.6 out of 5 stars
- 12 month limited warranty *view Terms & Conditions for details
- 96% of customers would recommend to a friend
| Specifications | |
|---|---|
| Pitch Spacing | 5.08mm |
| No. of Positions | 3Ways |
| Wire Size AWG Min | 26AWG |
| Wire Size AWG Max | 12AWG |
| Wire Connection Method | Screw |
| Rated Current | 16A |
| Rated Voltage | 300V |
| Block Orientation | Through Hole Right Angle |
| Product Range | MC00004 Series |
| Country of Origin: | Taiwan |
