5.08mm PCB Terminal Block, 2 Way, 26AWG to 12AWG, Screw - MC000034
5.08mm PCB Terminal Block, 2 Way, 26AWG to 12AWG, Screw - MC000034
Regular price
£1.39 GBP
Regular price
Sale price
£1.39 GBP
Unit price
/
per
Tax included.
Shipping calculated at checkout.
Couldn't load pickup availability
The MC000034 from Multicomp is a through hole, 2 position vertical terminal block with screw connection. This terminal block comes with 5.08mm pitch spacing and is suitable for wire size ranging from 26AWG to 12AWG. Single type terminal block; please note that modular terminal blocks are also available in the series allowing combining multiple modules together.
Product Info
- Green colour insulation
- Polyamide66 housing material
- Brass terminal
- Tin plating
- Operating temperature range from -40°C to 105°C
- PCB hole diameter of 1.5mm
- CUL and VDE approved
- Right angle wire orientation
- Multicomp products are rated 4.6 out of 5 stars
- 12 month limited warranty *view Terms & Conditions for details
- 96% of customers would recommend to a friend
| Details | |
|---|---|
| Pitch Spacing | 5.08mm |
| No. of Positions | 2Ways |
| Wire Size AWG Min | 26AWG |
| Wire Size AWG Max | 12AWG |
| Conductor Area CSA | 4mm2 |
| Wire Connection Method | Screw |
| Rated Current | 16A |
| Rated Voltage | 300V |
| Block Orientation | Through Hole Right Angle |
| Product Range | MB310 Series |
| Country of Origin: | Taiwan |
