5.08mm Pluggable Terminal Block, Plug - R/A, 2 Way, 24AWG to 14AWG, 16A - MC000184
5.08mm Pluggable Terminal Block, Plug - R/A, 2 Way, 24AWG to 14AWG, 16A - MC000184
Regular price
£1.89 GBP
Regular price
Sale price
£1.89 GBP
Unit price
/
per
Tax included.
Shipping calculated at checkout.
Couldn't load pickup availability
The MC000184 is a 2-way 16A right-angle Pluggable Terminal Block with green polyamide 66 insulating body, tin-plated phosphor bronze contacts and a nickel-plated steel screw. It has screw wire connection and 2000VAC minimum insulation withstand voltage.
Product Info
- >2000MR at 500V Insulation resistance
- 4.5lb-inch Screw torque
- -40 to 105°C Operating temperature range
- Multicomp products are rated 4.6 out of 5 stars
- 12 month limited warranty *view Terms & Conditions for details
- 96% of customers would recommend to a friend
| Details | |
|---|---|
| Pitch Spacing | 5.08mm |
| No. of Positions | 2Ways |
| Wire Size (AWG) | 24AWG to 14AWG |
| Wire Connection Method | Screw |
| Rated Current | 16A |
| Rated Voltage | 300V |
| Country of Origin: | Taiwan |
