5V, 10A, 50W, Enclosed Power Supply - LRS-50-5
5V, 10A, 50W, Enclosed Power Supply - LRS-50-5
Regular price
£27.99 GBP
Regular price
Sale price
£27.99 GBP
Unit price
/
per
Tax included.
Shipping calculated at checkout.
Couldn't load pickup availability
LRS-50 series 50W single output enclosed type power supply with 30mm of low profile design. Adopting the input of 85VAC or 264VAC. It features high efficiency up to 90%, long life and high reliability.
Features
- High efficiency up to 88%, long life and high reliability
- No load power consumption <0.21W
- Miniature size and 1U low profile
- High operating temperature up to 700C
- Short circuit/overload/overvoltage protections
- Cooling by free air convection
- Compliance to IEC/EN 60335-1(PD3) and IEC/EN61558-1,-2,-16 for household appliances
- LED indicator for power on
- Withstand 300VAC surge input for 5sec
- Dimension is 99mm x 82mm x 30mm
| Specifications | |
|---|---|
| Power Supply Approvals | ITE & Household |
| No. of Outputs | 1Outputs |
| Output Power Max | 50W |
| Output Voltage - Output 1 | 5V |
| Output Current - Output 1 | 10A |
| Input Voltage VAC | 85V AC to 264V AC |
| Power Supply Output Type | Adjustable, Fixed |
| Product Range | LRS-50 Series |
| Country of Origin: | China |
