5V, 18A, 90W, Enclosed Power Supply - LRS-100-5
5V, 18A, 90W, Enclosed Power Supply - LRS-100-5
Regular price
£29.39 GBP
Regular price
Sale price
£29.39 GBP
Unit price
/
per
Tax included.
Shipping calculated at checkout.
Couldn't load pickup availability
LRS-100 series 100W single output enclosed type power supply with 30mm of low profile design. Adopting the input of 85VAC to 264VAC (selectable by switch). It features high efficiency up to 91%, long life and high reliability.
Features
- Withstand 300VAC surge input for 5sec
- No load power consumption<0.3W
- Miniature size and 1U low profile
- High operating temperature up to 700C
- Short-circuit/overload/overvoltage protection
- Cool by free air convection
- Compliance to IEC/EN 60335-1 and IEC/EN61558-1,2-16 for household appliances
- LED indicator for power on
- Dimension is 129mm x 97mm x 30mm
| Specifications | |
|---|---|
| Power Supply Approvals | ITE & Household |
| No. of Outputs | 1Outputs |
| Output Power Max | 90W |
| Output Voltage - Output 1 | 5V |
| Output Current - Output 1 | 18A |
| Input Voltage VAC | 85V AC to 264V AC |
| Power Supply Output Type | Adjustable, Fixed |
| Product Range | LRS-100 Series |
| Country of Origin: | China |
