6 Channel, Buffers with TTL Compatible CMOS Inputs and 3 State Outputs, 4.5V to 5.5V, DIP 20, - CD74HCT244E
6 Channel, Buffers with TTL Compatible CMOS Inputs and 3 State Outputs, 4.5V to 5.5V, DIP 20, - CD74HCT244E
Regular price
£2.19 GBP
Regular price
Sale price
£2.19 GBP
Unit price
/
per
Tax included.
Shipping calculated at checkout.
Couldn't load pickup availability
The CD74HCT244E is a non-inverting 3-state Buffer has two active-low output enables. It features direct LSTTL input logic compatibility, VIL = 0.8V maximum, VIH = 2V minimum and CMOS input compatibility, Il <=1μA at VOL, VOH.
Features
- Buffered inputs
- High-current bus driver outputs
- Significant power reduction compared to LSTTL logic ICs
- Balanced propagation delay and transition times
- Standard outputs - 10 LSTTL loads
- Bus driver outputs - 15 LSTTL loads
| Specifications | |
|---|---|
| Logic Device Type | Buffer, Non Inverting |
| Logic Family / Base Number | 74HCT244 |
| Logic Case Style | DIP |
| No. of Pins | 20Pins |
| Supply Voltage Min | 4.5V |
| Supply Voltage Max | 5.5V |
| Logic IC Family | 74HCT |
| Logic IC Base Number | 74244 |
| Operating Temperature Min | -55°C |
| Operating Temperature Max | 125°C |
| Country of Origin: | Malaysia |
