ABS Enclosure, 66x55x131mm, Black, IP65 - 1594DWBK
ABS Enclosure, 66x55x131mm, Black, IP65 - 1594DWBK
Regular price
£21.49 GBP
Regular price
Sale price
£21.49 GBP
Unit price
/
per
Tax included.
Shipping calculated at checkout.
Couldn't load pickup availability
The 1594DWBK is a heavy duty electronic instrument Enclosure made of fire retardant ABS plastic ideally suited for mounting printed circuit boards. It has lap joint construction with a factory poured silicone rubber gasket around the perimeter of the lid provides protection against access of dust and water. The countersunk lid is secured with four M3 x 0.5, 18mm long stainless steel Philips machine screws threaded into integral brass bushings.
Features
- UL94V-0 Flammability rating
- Heavy duty, thick wall design with an average wall thickness of 3.3mm
- Countersunk screw heads use neoprene O-rings
- Silicone rubber gasket remains flexible from -62 to 232°C
| Specifications | |
|---|---|
| Enclosure Type | Instrument |
| Enclosure Material | ABS |
| External Height - Metric | 131mm |
| External Width - Metric | 66mm |
| External Depth - Metric | 55mm |
| IP Rating | IP65 |
| Body Colour | Black |
| External Height - Imperial | 5.16" |
| External Width - Imperial | 2.6" |
| External Depth - Imperial | 2.17" |
| Country of Origin: | Canada |
