AC/DC Encapsulated PCB Mount Power Supply, 24V, 1.04A, 25W - ECL25US24-E
AC/DC Encapsulated PCB Mount Power Supply, 24V, 1.04A, 25W - ECL25US24-E
Regular price
£69.29 GBP
Regular price
Sale price
£69.29 GBP
Unit price
/
per
Tax included.
Shipping calculated at checkout.
Couldn't load pickup availability
Features
- Ultra Compact Size
- Single, Dual & Triple Outputs
- Open Frame PCB & Chassis Mount
- Encapsulated PCB & Chassis Mount
- Less Than 0.3W No Load Input Power
- Peak Load Capability
- Class II Construction
- See Technical Note for information about XP Power's plans for the UKCA Marking
| Specifications | |
|---|---|
| Power Supply Applications | ITE |
| No. of Outputs | 1 Output |
| Output Power Max | 25W |
| Output Voltage - Output 1 | 24VDC |
| Output Current - Output 1 | 1.04A |
| Power Supply Output Type | Adjustable, Fixed |
| Input Voltage VAC | 85V AC to 264V AC |
| Width | 38.1mm |
| Height | 27.9mm |
| Depth | 78.7mm |
| Product Range | ECL25 Series |
| Country of Origin: | China |
