Development Board for GP-02 - GP-02-KIT
Development Board for GP-02 - GP-02-KIT
Regular price
£14.69 GBP
Regular price
Sale price
£14.69 GBP
Unit price
/
per
Tax included.
Shipping calculated at checkout.
Couldn't load pickup availability
GP-02-Kit is a highly integrated SOC development board with ceramic antenna and GP-02 high performance BDS/GNSS multi-mode satellite navigation receiver. The main chip is AT6558R satellite positioning chip. Integrated radio frequency front end, digital baseband processor, 32-bit RISC CPU, power management and active antenna detection and protection functions. Support a variety of satellite navigation systems, including China's BeiDou Navigation Satellite System (BDS), the United States' GPS, and Russia's GLONASS, which can realize multi-system joint positioning. GP-02-Kit follows the NMEA protocol and sends instructions through serial communication to control the work content of the development board.
Features
- Size 23.4x12.2x24(±0.2)MM
- Operating temperature range from -40°C to 85°C
- Power supply typical 5V (support micro USB 5V power supply)
- Maximum support 256000bps
| Specifications | |
|---|---|
| Kit Application Type | Sensing - Navigation, Position |
| Silicon Manufacturer | Shenzhen Qianle Microelectronics Technology |
| Silicon Core Number | AT6558R |
| Application Sub Type | BDS / GNSS |
| Kit Contents | Development Board AT6558R |
| Country of Origin: | China |
