Ftdi Breakout Module Based On Ft230xq Full Speed Usb To Basic Uart Ic Pcb Ended
Ftdi Breakout Module Based On Ft230xq Full Speed Usb To Basic Uart Ic Pcb Ended
Regular price
£12.19 GBP
Regular price
Sale price
£12.19 GBP
Unit price
/
per
Tax included.
Shipping calculated at checkout.
Couldn't load pickup availability
The UMFT230XB-NC is a Breakout Board with a low profile to convert USB to UART with four control bus lines. This module converts USB2.0 full-speed to a serial interface and connects the serial signals to a 2.54mm (0.1") pitch 10-pin female receptacle. The boards do not use USB connector, but instead the modules plug directly into the USB host connector and the pads of the PCB makes electrical contact with the electrical contacts of the USB connector. All serial interfaces on these modules operate at 3.3V voltage levels, however all I/Os are 5V tolerant.
Features
- 3.3V Power out with a 50mA current limit and fused 5V
- UART rate can be up to 3MBd
- No connector option, no connector is fitted to CN2
- Configurable CBUS I/O pin
- Device supplied preprogrammed with unique USB serial number
- Supports bus powered, self powered and high power bus powered USB configurations
- Integrated power on reset circuit
- Low USB bandwidth consumption
- UHCI/OHCI/EHCI host controller compatible
- USB 2.0 full speed compatible
| Specifications | |
|---|---|
| Silicon Manufacturer: | FTDI |
| Silicon Core Number: | FT230XB |
| Kit Application Type: | Interface Module |
| Application Sub Type: | USB to UART |
| Kit Contents: | Dev Board FT230XB |
| Features: | Full Speed USB2.0, 3Mbaud UART, 4 Control Bus Lines, Embedded ROM, 3.3V O/P, USB Powered |
| Country of Origin: | China |
