Ftdi Breakout Module Based On Ft230xq Full Speed Usb To Basic Uart Ic Socket Pin
Ftdi Breakout Module Based On Ft230xq Full Speed Usb To Basic Uart Ic Socket Pin
Regular price
£12.09 GBP
Regular price
Sale price
£12.09 GBP
Unit price
/
per
Tax included.
Shipping calculated at checkout.
Couldn't load pickup availability
UMFT230XB-01 breakout module utilizes FT230XQ IC to convert USB to basic UART module. UMFT230XB bridges from USB to UART IC. This hardware is a low cost breakout board form factor that converts USB2.0 full speed to a serial interface and connects the serial signals to a 2.54mm (0.1inch) pitch 10pin female receptacle. The boards do not use a USB connector, but instead the modules plug directly into the USB host connector and the pads of the PCB makes electrical contact with the electrical contacts of the USB connector.
Features
- Single chip USB to asynchronous serial data transfer interface
- Entire USB protocol handled on the chip. No USB specific firmware programming required
- Royalty free VCP and D2XX drivers eliminate the requirement for USB driver development in most cases
- Configurable CBUS I/O pin
- Device supplied preprogrammed with unique USB serial number
- Supports bus powered, self powered and high power bus powered USB configurations
- Integrated power on reset circuit
- Low USB bandwidth consumption
- UHCI/OHCI/EHCI host controller compatible
- USB 2.0 full speed compatible
| Specifications | |
|---|---|
| Accessory Type: | USB to I2C Breakout Module |
| Features: | USB Battery Charger Detection, Data Transfer Rates from 300baud to 3Mbaud at TTL Levels |
| Country of Origin: | China |
