Hameg - HMC8012G - Dmm, Auto/manual, 12 Function & Ieee-488
Hameg - HMC8012G - Dmm, Auto/manual, 12 Function & Ieee-488
Regular price
£1,248.49 GBP
Regular price
Sale price
£1,248.49 GBP
Unit price
/
per
Tax included.
Shipping calculated at checkout.
Couldn't load pickup availability
The HMC8012 in contrast to the class standard of 5-1⁄2 digit displays, the HAMEG instrument offers a 5-3⁄4 digit display (480,000 counts) resulting in measurement ranges that are four times higher without any requirements of range switching. It facilitates measurements in the measurement category II with a voltage of up to 600 V, as opposed to the standard of only 300 V in this instrument class. With the HMC8012, current measurements across the entire range can be performed with only one connector. This eliminates any manual switching during range transfers. Additionally, an integrated watt meter enables power measurement in the DC range.
Features
- Simultaneous Display of 3 Measurements, e.g. DC + AC + Statistics
- Up to 200 Measurements per Second
- DC Basic Accuracy 0,015%
- 12 Measurements Functions
- Crisp colour TFT display for excellent readability
- Resolution: 1μV, 100 nA, 1mR, 1pF, 1Hz, 0,1 °C
- True RMS Measurement AC, AC + DC
- Mathematic Functions: Limit Testing, Minimum/Maximum, Average, Offset, DC Power, dB, dBm
- Temperature Measurements with Platinum Sensors
- Data Logging in .CSV-Format to Internal Memory or USB-Stick
| Specifications | |
|---|---|
| DMM Functions: | Current, Voltage, Capacitance, Frequency, Resistance, Temperature |
| Current Measure AC Max: | 10A |
| Current Measure DC Max: | 10A |
| Voltage Measure AC Max: | 750V |
| Voltage Measure DC Max: | 1kV |
| Resistance Measure Max: | 0.25Gohm |
| DMM Connectivity: | GPIB, LAN / LXI, USB |
| No. of Digits: | 5.75 |
| Product Contents: | Line cord, printed operating manual, HZ15 Silicon test lead with safety connector and test probe, 1m (black + red), Software-CD |
| Country of Origin: | Czech Republic |
