Monacor - RF-EXPLORER/6 - Frequency Scanner, 6 Ghz
Monacor - RF-EXPLORER/6 - Frequency Scanner, 6 Ghz
Regular price
£451.99 GBP
Regular price
Sale price
£451.99 GBP
Unit price
/
per
Tax included.
Shipping calculated at checkout.
Couldn't load pickup availability
6GHz RF spectrum analyser, in a compact aluminium housing with two antennas (SMA connection) for the different frequency ranges, including to prevent frequency collisions when setting up radio links in the frequency range mentioned above.
Features
- Frequency range: 15-6,100MHz (6GHz)
- Real-time monitoring of the frequency range used with indication of frequency and level (dBm and dBμV)
- Backlit high-contrast graphic display (128x64 pixels)
- Auto marker function and manual marker positioning for setting an individual carrier frequency
- Special WiFi analyser with display of 13 WLAN channels
- Max hold function for a reliable detection of ultra-short RF carrier frequencies (additional modes: normal, max., average, overwrite)
- Mini USB 2.0 interface for connecting to a PC or laptop as well as for charging the built-in rechargeable lithium polymer battery (1,000mAh)
- Supplied with transport bag and USB cable
| Specifications | |
|---|---|
| External Width: | 71 mm |
| Weight: | 210 g |
| External Length / Height: | 122 mm |
| External Depth: | 25 mm |
| Important Product Info: | Client software with real-time analysis for Windows* XP/Vista/Win7/Win8 (32-bit or 64-bit version) can be downloaded at monacor website |
| Country of Origin: | China |
