Quartz Crystal, 16MHz, 11.5mm x 5mm, 10ppm, 18pF, 10ppm - 9B-16.000MEEJ-B
Quartz Crystal, 16MHz, 11.5mm x 5mm, 10ppm, 18pF, 10ppm - 9B-16.000MEEJ-B
Regular price
£1.69 GBP
Regular price
Sale price
£1.69 GBP
Unit price
/
per
Tax included.
Shipping calculated at checkout.
Couldn't load pickup availability
The 9B-16.000MEEJ-B is a through-hole Quartz Crystal with highly mass production capability. The resistance welded type crystal unit offers a great number of standard frequencies, higher frequency pullability and lower equivalent series resistance.
Features
- ±3ppm/year Maximum aging
- -20 to 70°C Operating temperature range
| Specifications | |
|---|---|
| Frequency Nom | 16MHz |
| Crystal Case | Through Hole, 11.5mm x 5mm |
| Frequency Stability + / - | 10ppm |
| Load Capacitance | 18pF |
| Frequency Tolerance + / - | 10ppm |
| Product Range | 9B Series |
| Operating Temperature Min | -20°C |
| Operating Temperature Max | 70°C |
| Country of Origin: | China |
