Recom Power - RD-1205D - Dc/dc Converter, 2w, Dual, 5v
Recom Power - RD-1205D - Dc/dc Converter, 2w, Dual, 5v
Regular price
£8.69 GBP
Regular price
Sale price
£8.69 GBP
Unit price
/
per
Tax included.
Shipping calculated at checkout.
Couldn't load pickup availability
The RD-1205D is a 2-output 2W board-mount unregulated ECONOLINE DC/DC Converter has been specifically designed for applications where dual power rails need to be created from a single rail supply is required. With efficiencies up to 85%, the full output power is available over the operating temperature range -40 to 85°C and the converter can be used in ambient temperatures of up to 100°C with derating. The selection of industry standard 12VDC input and ±5VDC output voltage options makes this converter suitable for many industrial applications.
Product Info
- Power sharing on outputs
- 75 to 82% Efficiency
- ±470μF Maximum capacitive load
| Details | |
|---|---|
| DC / DC Converter Output Type: | Fixed |
| No. of Outputs: | 2 Output |
| Input Voltage DC Min: | 10.8V |
| Input Voltage DC Max: | 13.2V |
| Output Power Max: | 2W |
| Output Voltage - Output 1: | 5V |
| Output Voltage - Output 2: | -5V |
| Output Current - Output 1: | 200mA |
| Output Current - Output 2: | 200mA |
| DC / DC Converter Type: | SIP |
| DC / DC Converter Mounting: | Through Hole |
| Width: | 7.05mm |
| Height: | 10.2mm |
| Depth: | 19.65mm |
| Product Range: | RD Series |
| Country of Origin: | Taiwan |
