Schneider Electric / Telemecanique - GV2ME08 - Circuit Breaker, 3 Pole, 2.5a To 4.0a
Schneider Electric / Telemecanique - GV2ME08 - Circuit Breaker, 3 Pole, 2.5a To 4.0a
Regular price
£83.59 GBP
Regular price
Sale price
£83.59 GBP
Unit price
/
per
Tax included.
Shipping calculated at checkout.
Couldn't load pickup availability
The GV2ME08 from Schneider is a TeSys three pole thermal magnetic circuit breaker with screw clamp terminals. This circuit breaker is approved by EN 60204, IEC 60947-1, IEC 60947-2, IEC 60947-4-1, NF C 63-120, NF C 63-650, NF C 79-130, UL 508, VDE 0113, VDE 0660 and CSA C22.2 standards. The GV2ME08 is DIN rail mountable with vertical and horizontal mounting positions.
Features
- Breaking capacity of 3KA at 690VAC (50/60Hz) conforming to IEC 60947-2
- Thermal protection adjustment range from 2.5A to 4A
- Magnetic tripping current is 51A
- Rated operational voltage of 690VAC (50/60Hz) conforming to IEC 60947-2
- Conventional free air thermal current of 4A conforming to IEC 60947-4-1
- Power dissipation per pole is 2.5W
- IP20 degree of protection conforming to IEC 60529
- IK04 degree of protection
- Operating ambient air temperature range from -20°C to 60°C
- Pushbutton control
| Specifications | |
|---|---|
| Current Rating: | 4A |
| Circuit Breaker Mounting: | DIN Rail |
| No. of Poles: | 3 Pole |
| Product Range: | GV2M Series |
| Voltage Rating V AC: | 690 VAC |
| Country of Origin: | France |
