SMD Chip Resistor, 0805 [2012 Metric], 100kohm - VISHAY

SMD Chip Resistor, 0805 [2012 Metric], 100kohm - VISHAY

£0.99 GBP
£0.99 GBP
Sale Sold out
Tax included. Shipping calculated at checkout.

The Vishay D/CRCW e3 series are standard thick film chip resistors. The resistance range includes E96 and E24 decade values from 1ohm to 10Mohm. CRCW e3 series resistors have a pure tin solder contacts on the Ni barrier layer that provides compatibility with reflow soldering process.

Product Info

  1. Automotive grade AEC-Q200 qualified
  2. EIA 0402, 0603, 0805, 1206, 1210, 1218, 2010, 2512 standard case sizes available
  3. Stability ΔR/R = 1% for 1000h at 70°C
  4. Metal glaze on high quality ceramic
  5. Zero ohm jumper are available for all sizes
  6. 2mm pitch packaging option for 0603 size
  7. Available in ±1% and ±5% tolerance
  8. ±100ppm/K and ±200ppm/K TCR values available
  9. Operating temperature range -55°C to +155°C
  10. Maximum power rating is 1W

Details
Resistor Case Style 0805 [2012 Metric]
Resistance 100kohm
Product Range CRCW e3 Series
Voltage Rating 150V
Resistor Element Type Thick Film
Power Rating 125mW
Resistance Tolerance ± 1%
Temperature Coefficient ± 100ppm/K
Automotive Qualification Standard AEC-Q200
Country of Origin: Israel

EAN:
Manufacturer Part Number:
