SMD Chip Resistor, 47 kohm, WF06P Series - WALSIN
SMD Chip Resistor, 47 kohm, WF06P Series - WALSIN
Regular price
£1.09 GBP
Regular price
Sale price
£1.09 GBP
Unit price
/
per
Tax included.
Shipping calculated at checkout.
Couldn't load pickup availability
The WF08P series resistors from Walsin are high power chip resistors. These resistors are constructed in a high grade ceramic body (aluminium oxide). The WF08P resistors are used in high accuracy DC power supplies, digital multimeters, telecommunications, computers, medical and military equipments.
Product Info
- Resistance range includes E24 & E96 decade values from 1ohm to 1Mohm
- EIA 0805 case size
- <=±100ppm/°C and <=±150ppm/°C TCR values available
- Available in ±1% and ±5% tolerance
- Operating temperature range of -55°C to 155°C
- High reliability, high precision and stability
- Reduced size of final equipment, small size and light weight
- Jumpers are also available
- Meets JIS C 5201-1:1998 / IEC 60068-2-58:2004 standards
- Continuous working voltage of 150V and rated power of 250mW
| Details | |
|---|---|
| Resistance | 47kohm |
| Product Range | WF06P Series |
| Voltage Rating | 150V |
| Resistor Element Type | Thick Film |
| Resistor Case Style | 0805 [2012 Metric] |
| Power Rating | 250mW |
| Resistance Tolerance | ± 1% |
| Temperature Coefficient | ± 100ppm/°C |
| Country of Origin: | China |
