VM110N Velleman Kit Usb Experiment Interface Board

The VM110N mounted interface board has 5 digital input channels and 8 digital output channels. There are also two analogue inputs and outputs with 8-bit resolution. The number of inputs/outputs can be further expanded by connecting up to 4 more cards to the PC's USB connectors. All communication routines are contained in a Dynamic Link Library (DLL). You can write custom Windows (98SE, 2000, ME, XP) applications in Delphi, Visual Basic, C++ Builder or any other 32-bit Windows application development tool that supports calls to a DLL.

• 5 Digital inputs (0=ground, 1=open) (on board test buttons provided)
• 2 Analogue inputs with attenuation and amplification option (internal test +5V provided)
• 8 Digital open collector output switches (50V/100mA max.) (on board LED indication)
• 2 Analogue outputs
• 0-5V, Output resistance 1K5
• PWM 0-100% open collector outputs max. 100mA/40V (on board LED indication)
• General conversion time: 20ms per command
• Power supply through USB: 70mA approx
• Diagnostic software with DLL included
• Dimensions (WxHxD): 145x20x88mm
